NEXUS STANDARD MP V3+
The Standard MP V3+ is our latest model release. A VLF Induction Balance metal detector. Designed to operate in manual mode which still remains the
best way to achieve maximum performance and results.
CHARACTERISTICS● A masterful performer on every terrain and search conditions.
● Extraordinarily stable on both normal and high mineral conditions.
● Superb discrimination - precise identification of deep large Iron targets. ● Low sensitivity to tiny, useless items like bits of lead, foil and thin wires, yet will never miss a very small coin. ● Stable performance close to EMI (electromagnetic interference) ● Finds valuable targets under Iron Stones too big for other IBD’s to ignore or penetrate. ● Higher resolution of adjustment than any other IB detector, digital and analogue alike. ● Constant thermal stability over time, no drift regardless of environmental temperature or moisture changes.● Faster recovery speed.
● Top performance on every salt water tidal beach. FEATURES Super Damping Technology ● Extends the limits of IB technology in all soil conditions. ● Maximizes efficiency of ground and mineral suppression, removes interferance caused by minerals. ● Uses the ground conductivity to enhance metal target detection, results better in ground, than in air. RGB meter for visual target identification RGB led meter indicating 3 conductivity ranges for non-ferrous. ● Green - Lowest conductors. Examples: Gold coins and small Aluminium fragments. ● Orange - Medium conductors. Examples: Lead, Copper, Bronze ● Purple / White. Highest conductors. Examples: Mostly Silver targets. ● Blue - Iron Depth Clear detection of 50 cm copper pan at 3 meters depth with dual 31 inch search coil. VCO Adaptable recovery speed in the VCO (multi tones) audio. Accurate discrimination of all non-ferrous targets at maximum detection depth. CONTROLS ● Battery test toggle switch ● Volume combined with on/off ● Ground balance - Dual ground balance: Fine multi turn and Coarse single turn. ● Mineral control - Fine Mineral Control with on/off togle switch. ● Discrimination ● Target isolation with LC-MC Set for isolating hammered gold coins and other small gold items from almost all other non-ferrous targets● Iron rejection / VCO switch - Iron rejection when pushed forward. When pulled back, enables VCO momentary. When released returns to off state.
OTHER FEATURES ● 4 pole, carbon fiber shaft. ● 12 hour battery life. ● Built in loudspeaker. ● Headphone socket ● Battery recharge socket ● 10 AA battery compartment. (SIngle batteries or rechargeable pack.)
GROUND BALANCE PROCEDURE - Nexus Standard MP V3 VLF Induction Balance Metal Detector
1. Turn the detector on from the Volume control.
2. Set the audio to a level comfortable for you.
3. Set the threshold to a barely audible level.
4. Set the discrimination level to 0 if a low frequency coil is fitted. For high frequency coils the
discrimination level will be different. Read the User Manual on how to set the discrimination level.
5. Mineral Control and VCO Off.
6. Find ground free from metal.
7. Turn the Coarse Gb knob to 10 (fully clockwise).
8. Begin moving the search coil up and down between 8 cm and 25 cm above ground.
9. If the detector beeps while the search coil is going up - turn the Fine GB knob slightly to the right.
10. If the detector beeps while the search coil is going down - turn the Fine GB knob slightly to the left.
11. Keep repeating step 8. & 9. until there are no beeping sounds when the search coil moves up and down.
If the Fine GB is out of range (the detector beeps only when the coil goes down) then turn the Coarse GB to 9.5-9 to set a different GB range.
SEARCH COILS
USEFUL ARTICLES
Coming Soon
Coming Soon
Coming Soon
PI COILS
MP V3
TWO BOX
MP V3+
3D TEST
VIDEOS
CONTACT
NEXUS STANDARD MP V3+
The Standard MP V3+ is our latest model release. A
VLF Induction Balance metal detector. Designed to
operate in manual mode which still remains the best
way to achieve maximum performance and results.
CHARACTERISTICS● A masterful performer on every terrain and search
conditions.
● Extraordinarily stable on both normal and high
mineral conditions.
● Superb discrimination - precise identification of deep large Iron targets. ● Low sensitivity to tiny, useless items like lead bits, foil and thin wires, yet will never miss a very small coin. ● Stable performance close to EMI (electromagnetic interference) ● Finds valuable targets under Iron Stones too big for other IBD’s to ignore or penetrate. ● Higher resolution of adjustment than any other IB detector, digital and analogue alike. ● Constant thermal stability over time, no drift regardless of environmental temperature or moisture changes.● Faster recovery speed.
● Top performance on every salt water tidal beach. FEATURES Super Damping Technology ● Extends the limits of IB technology in all soil. ● Maximizes efficiency of ground and mineral suppression, removes interferance caused by minerals. ● Uses the ground conductivity to enhance metal target detection, results better in ground, than in air. RGB meter for visual target identification RGB led meter indicating 3 conductivity ranges for non-ferrous. ● Green - Lowest conductors. Examples: Gold coins and small Aluminium fragments. ● Orange - Medium conductors. Examples: Lead, Copper, Bronze ● Purple / White. Highest conductors. Examples: Mostly Silver targets. ● Blue - Iron Depth Clear detection of 50 cm copper pan at 3 meters depth with dual 31 inch search coil. VCO Adaptable recovery speed in the VCO (multi tones) audio. Accurate discrimination of all non-ferrous targets at maximum detection depth. CONTROLS ● Battery test toggle switch. ● Volume combined with on/off ● Ground balance - Dual ground balance: Fine multi turn and Coarse single turn. ● Mineral control - Fine Mineral Control with on/off toggle switch. ● Discrimination ● Target isolation with LC-MC Set for isolating hammered gold coins and other small gold items from almost all other non-ferrous targets● Iron rejection / VCO switch - Iron rejection when
pushed forward. When pulled back, enables VCO
momentary. When released returns to off state.
OTHER FEATURES ● 4 pole, carbon fiber shaft. ● 12 hour battery life. ● Built in loudspeaker. ● Headphone socket ● Battery recharge socket ● 10 AA battery compartment. (SIngle batteries or rechargeable pack.) SEARCH COILS
GROUND BALANCE PROCEDURE
1. Turn the detector on from the
Volume control.
2. Set the audio to a level comfortable
for you.
3. Set the threshold to a barely
audible level.
4. Set the discrimination level to
0 if a low frequency coil is
fitted. For high frequency
coils the discrimination
level will be different.
Read the User Guide
on how to set the discrimination level.
5. Mineral Control and VCO Off.
6. Find ground free from metal.
7. Turn the Coarse Gb knob to 10 (fully clockwise).
8. Begin moving the search coil up and down between
8 cm and 25 cm above ground.
9. If the detector beeps while the search coil is going
up - turn the Fine GB knob slightly to the right.
10. If the detector beeps while the search coil is going
down - turn the Fine GB knob slightly to the left.
11. Keep repeating step 8. & 9. until there are no
beeping sounds when the search coil moves up and
down.
If the Fine GB is out of range (the detector beeps only
when the coil goes down) then turn the Coarse GB to
9.5-9 to set a different GB range.
Coming Soon
Coming Soon
Coming Soon
* Carbon Fibre - low weight for size.
USEFUL ARTICLES
